Overland Rally Navigation Package Pro Yamaha

Overland Navigation Package PRO

Save with Overland Navigation Pro Level package.
This package meets DAKAR and FIM Rallies Requirements and designed to be used in combination with other different rally parts of your choice. Please note that the navigation tower is bike specific so in case of any confusion please send us your bike model beforehand to be sure.
Parts comes separately for you to assemble.

The package includes the following:
1. PRO Rally Navigation Tower -no drill
2. F2r 850 Roadbook holder
3. Tripmeter/Tripmaster —(Option 1 ) 1 x RNS TripMaster XL4 –new model – Or (Option 2) ICO Rallye MAX 2 (30 Euro Extra)
4. 1 x ICO ICO Rallye MAX-G
5. 1 x f2r Rallye Power Box (PB001)
6. 2 x F2r RB and tripmaster combo remote (CR001)
Description:
1. PRO Rally Navigation Tower – no drill —KTM/Husqvarna Models

– For Yamaha WR -YZ
Main Features:

Meets DAKAR and FIM Rallies Requirements
Plug&Play (NO welding, NO Drilling)
10 Minutes Installation Time
ERTF GPS/IRITRACK Antennas Brakcet
Roadbook Holder Bracket (MigTec/MD or F2R)
SMALLTRACK Bracket Ready
IRITRACK Bracket
Possibility to install: 2 SPEEDOCAP + 1 TRIPMASTER / 1 SPEEDOCAP + 2 TRIPMASTER
6 way Fuse Box
2 USB Charging Ports
Voltmeter Display
2 on/off switches
LED Lights Brackets
Adjustable Instruments Height and Inclination
Fairing Quick Release Buckles and Brackets included
GPS Bracket Adaptor to install Garmin or Trailtech Voyager Pro GPS systems
*Led lights not included

2. F2r 850 Electric Roadbook:
(RB main unit only configuration)
• New innovative transmission works all along the roadbook from first to last note
• Holds roadbook paper rolls up to 55 mm thickness (more than 18 meters long and 500 notes)
• Build in aluminum for high mechanical resistance and lightness.
• High water and dust resistance for severe conditions use.
• Aluminum and highly transparent polycarbonate cover with a view area of 150x105mm and double lock
• Include internal led light for night navigation
• Attractive design
• Dimensions : 195x130x75 mm (excluding knobs)
• Weight : 780gr

3. Tripmeter/Tripmaster
Option 1 – RNS TripMaster XL4:
Hardware Design:
– CNC machined aluminium casing, anodised in gunmetal grey
– Sun visor integrated into the casing, no more ugly duct-tape solutions!
– 2 click-feedback rubber buttons on the left side for easy pressing even when wearing gloves
– Water and dust proof design, also applies to connectors
– Large, wide and contrast-strong 18mm tall digits
– Perfect readability under bright sunlight and dust
– Battery operation with a runtime of several months (1x CR2032, included)
– External 12V power supply required to operate the light blue LED backlight
Software Functions:
– 2x individually adjustable trips: A and B
– Each with a selectable resolution of 100m or 10m
– Trip B can be switched off
– Speed display
– Current speed
– Top speed
– Wheel circumference adjustable with 1mm accuracy
– Automatic wheel calibration function
– Integrated odometers
– Resettable “oil change” odometer
– Static/non-resettable lifetime odometer
– 24-hour Clock
Includes:
– Front wheel sensor (M8 screw type)
– Strong neodym wheel magnet
– Power connector
– Mounting parts: grommets, washers and nuts
– Weight 300 g

Option 2 (30 Euro Extra) : ICO Rallye MAX 2
The highly reliable Odometer used by the rallies/raid professional and factory top teams.
Rallye MAX 2™ is the next step in a thirty-year evolution. It’s also fully compatible with the previous Rallye MAX™
Functions:
• Adjustable odometer
• Speedometer with resettable peak speed mode
• Stage timer
• Resettable hour meter tracks maintenance intervals
• Resettable second trip odometer
• Total lifetime distance stored into permanent memory
• (NEW) No batteries! Internal emergency power that last for days!

Features:
• (NEW) Wake from sleep on wheel movement
• Switch between kilometers and miles without adjusting wheel circumference (mm)
• AutoCal™ automatically adjusts to match the route
• New OdoQuick™ feature eliminates mode changes to check odometer while in a speed zone
• New OdoPause™ feature makes adjustments easier while moving
• 180º vertical viewing angle
• Large, sharp contrast digits
• 11 helpful icons improve ease of use
• Adjustable backlight has night mode (dim) and day mode (bright)
• Includes aluminum bracket for mounting computer to handlebar clamps
• Designed to be powered from the motorcycle’s 12V battery during normal usage
• (NEW) Runs for up to 7 Dakar-length stages on internal emergency power
• Auto shut off after 20 minutes
• Rugged, stainless steel sensor and aluminum mounting bracket
• For KTM/Husaberg/Husqvarna riders, the sensor screws directly into the OEM sensor hole
• Strong rare earth sensor magnet

Physical Specs :
• Case Size – 93mm x 47mm x 30mm deep
• Color – BLACK
• Weight – 120 grams
Package Includes :
• Rallye MAX™ computer
• (NEW) New style 3-button remote thumb switch (available soon as spare)
• Sensor cable with bracket (available also as spare – see below)
• Magnet and mounting accessories (available also as spare – see below)
• Power cable (available also as spare – see below)
• Instruction manual (also available for download in English)

4. ICO Rallye MAX-G
The ICO Rallye MAX-G™ is an all-in-one, GPS-based compass repeater and rally odometer from ICO RACING.
For experienced rally racers, the ICO Rallye MAX-G™ is the ideal companion to the ICO Rallye MAX™.
Many racers prefer to have two displays and a wheel sensor-based primary odometer.
The ICO Rallye MAX-G™ is a race-ready compass repeater and an excellent backup odometer.
For casual rally enthusiasts and dual sport riders, the ICO Rallye MAX-G™ is the perfect standalone instrument.
It combines all the functions needed for dual sport rides, rally training, and smaller rally raid events.

Functions :
• Adjustable odometer
• CAP compass heading display
• Speedometer with resettable peak speed mode
• GPS-based time-of-day clock
• Resettable hour meter tracks maintenance intervals
• Resettable second trip odometer
• Total lifetime distance stored into permanent memory
Features :
• Switch between kilometers and miles without adjusting wheel circumference (mm)
• Small GPS receiver can be mounted almost anywhere with a zip-tie
• New GPS updates 5x faster (5 updates per second)
• Almost instant “warm” satellite acquisition
• AutoCal™ automatically adjusts to match the route
• New OdoQuick™ feature eliminates mode changes to check odometer while in a speed zone
• New OdoPause™ feature makes adjustments easier while moving
• 180º vertical viewing angle
• Large, sharp contrast digits
• 11 helpful icons improve ease of use
• Adjustable backlight has night mode (dim) and day mode (bright)
• Auto shut off after 2 hours of no activity
• Includes aluminum bracket for mounting computer to handlebar clamps
• Requires a hard-wired connection to the motorcycle’s 12V battery (NO Batteries)
• CR001 (lefthand) and CR002 (righthand) F2R Remote combos full compatibility

Physical Specs :
• Case Size – 93mm x 47mm x 30mm deep
• Color – BLACK
• Weight – 120 grams
Package Includes :
• Rallye MAX-G™ computer
• New, faster GPS receiver
• New style 3-button remote thumb switch (available soon as spare)
• Mounting bracket and hardware
• Power cable (available also as spare – see below)
• Instruction manual (also available for download in English and German)

5. Rallye Power Box
provides a central, compact and reliable power supply and connectivity point for all rallye navigation equipments, namely :
• 2 x ICO/RNS trip computer or compatible
• 1 x electric F2R Roadbook holder (main unit and remote) or compatible
• 1 x spare port for other navigation equipment (ex: GPS, tracker, etc)
Features :
• Compact design (70x36x24mm) and high resistant construction
• Power led indicator
• Battery connection cable with 2A fuse protection (*)
• Water and dust proof (IP67) box and connectors.
Includes :
• Rally Power Box with battery power cable
• 2 x ICO power extension cables
• 1 x power extension cable for spare port (bare wires)
• 5 x socket caps for unused socket protection
(*) Power cable can be easily connected to the 12V bike battery or to a switched source.

F2r RB and tripmaster combo remote (CR001):
Heavy duty integrated remote switch for your roadbook holder and tripmaster.
– Robust aluminium case anodised in black
– Ergonomic design
– Water and dust protected (including connectors)
– Easy installation and maintenance.

6. 2 x RB and tripmaster combo remote
1 x right hand remote mounted
1 x left hand remote mounted
• 3 x high sensitive buttons (even with gloves) in an ergonomic position
• Connects directly to ICO Rallye MAX™, ICO Rallye MAX-G™, ICO Rallye VR Light (grey), Rallye CAP™ and ICO Rallye 2000 (red)
• Supports Touratech IMO 100R50 Rallye, IMO 100R300 and KTM Tripmaster (*)
Roadbook holder switch
• Robust and low force operation toggle switch
• Connects directly F2R RB850 Rally ,F2R RB750 Rally and F2R RB730 (version B)
• Connects F2R RB730 (version A), MD and Touratech (RBTT i and RBTT *MvG*) roadbook holders through RB adapter cable (included)
Package includes :
• Remote combo and cables
• Fixing clamp and screws
• RB adapter cable
• Mounting and wiring instructions
