KTM EXC 2012-2016 Rally RAID -Dakar ready Kit


KTM EXC 2012-2016 Rally Kit
Thinking about racing the Dakar Rally or another International Rally? This full kit will turn your KTM EXC 2012-2016 into a ready to race bike that meets all FIM Regulations. It comes with complete navigation equipment and is a plug&play solution that doesn’t require any welding nor drilling.
The fuel capacity on this bike is almost 30 litres which translates into an autonomy of over 300 km on off road riding. The tanks are made out of plastic and are directly connected to each other without the need of an extra pump. In case you do not need the Dakar minimum autonomy (250km + 10%) you can race this kit even with the front OEM EXC fuel tank.
– 15 Litres Front Plastic Tank
– 14.5 Litres Rear Plastic Tank with Complete Rear Subframe

– For the first time in rally history you will be able to troubleshoot the diagnosis of your bike at the touch of a hand thanks to the WiFi connection between your smartphone and Ecu unit. No need of internet, just simply connect directly to the Ecu!

– Using the direct WiFi connection you will also have the chance to fully customize your setting and even modify ignition and fuel injection.

10 level Traction control on your handlebar thanks to the GPA switch which lets you adjust on the go the traction of your bike while you are riding. Switch from the different levels without the need to stop and find the perfect traction on all surfaces.

– Water Reserve
– Toolbox
– Water Pump Protection
– The first dismountable Ktm Orange RB/Trip Switch
– Quick Release Disconnect
– Special Hose
– Decide which tank to use
The Ktm Exc 450-500 Rally comes equipped with the complete navigation system which consists in:

– Electric Roadbook Holder (With Backlight)

– RNS Tripmaster (With Backlight)

– REBEL Handlebar Command (Roadbook/Tripmaster)

Furthermore the position of the navigation system can be adjusted increasing or decreasing the angle of the support plate. Always on the nav support there is space for a 2nd trip master underneath the road book holder and a Speedocap on the top.

The navigation tower is machined from solid and uses a new patented system where it is mounted directly inside the steering head without any holes drilled on the frame. The tower also has:

– Iritrack Support Bracket

– ERTF and TDCOM Antenna’s Support Bracket

– Speedocap Mount

– 2nd Tripmaster Mount

– Fuse Box
The rally kit comes with a complete crystal material sticker kit which other than giving the looks of the Ktm EXC 2016 model range to your bike it also acts as a protection due to the thick adhesive material used. There is also the possibility to have the Rally kit with a custom graphic to feature team sponsors and logos.

Research and development have been done by qualified technicians and through harsh test both on the dyno and with riders in order to achieve a ready to race bike that delivers an improved performance also on the engine side compared to the OEM Ktm EXC.

– Increased High RPM Range Performance

– Increased Low RPM Range Performance

– ECU Special Rally Mapping

– 100% Made in Italy
